MikroTik CCR2116-12G-4S+ – 16-Core Cloud Core Router with 4x 10G SFP+
Availability:
In Stock
| CPU | AL73400 (Annapurna Labs Alpine v3) |
| RAM | 16 GB |
| Gigabit Ethernet Ports | 13 (12 + 1 management) |
| SFP+ Ports | 4 x 10G |
| Operating System | RouterOS v7, Level 6 |
Description
Product Description
CCR2116-12G-4S+ – 16-Core ARM CPU 10G Cloud Core Router
The MikroTik CCR2116-12G-4S+ is the new standard of single-core performance in the entire CCR product family. Powered by the Amazon Annapurna Labs Alpine v3 AL73400 CPU with 16 cores running at 2 GHz, it delivers up to 6x faster BGP performance than previous CCR generations. Four 10G SFP+ ports with separate full-duplex lines to the Marvell Aldrin family switch chip, twelve Gigabit Ethernet ports, an M.2 PCIe 3.0 slot for NVMe storage, 16 GB of RAM and 128 MB of NAND storage. Dual redundant power supplies and Layer 3 Hardware Offloading make this router the perfect fit for large ISPs.
Top Features
- 16-Core ARM CPU at 2 GHz: Amazon Annapurna Labs Alpine v3 AL73400.
- Layer 3 Hardware Offloading: Free CPU cores for BGP, VPN, containers.
- 4x 10G SFP+ + 12x Gigabit Ethernet: Full-duplex Marvell switch chip.
- 16 GB RAM + M.2 PCIe Slot: Premium memory and NVMe storage support.
- Dual Redundant Power Supplies: Zero-downtime carrier-grade reliability.
| Category | Specification |
|---|---|
| Processing and Performance | |
| Product Code | CCR2116-12G-4S+ |
| CPU | AL73400 (Annapurna Labs Alpine v3) |
| CPU Cores / Frequency | 16 cores at 2 GHz |
| Switch Chip | Marvell 98DX3255 (Aldrin family) |
| RAM | 16 GB |
| Storage | 128 MB NAND + M.2 PCIe 3.0 x4 slot |
| Operating System | RouterOS v7, Level 6 |
| Layer 3 Offloading | Yes |
| Ports and Connectivity | |
| Gigabit Ethernet Ports | 13 (12 + 1 management) |
| SFP+ Ports | 4 x 10G |
| Powering and Dimensions | |
| Power Supply | Dual redundant AC (100-240 V) |
| Dimensions | 443 x 250 x 44 mm (1U rack) |
| Cooling | Active (fans) |
Backed by MikroTik's commitment to quality, this device ships with RouterOS pre-installed and licensed. Free software updates are included for the life of the product or a minimum of 5 years from date of purchase. The device is fully compliant with applicable safety certifications. Refer to the official MikroTik documentation for warranty terms and configuration guidance.
