Kwikset Signature Series 2nd Gen Round Smart Lock

$ 174.75
Availability: Out Of Stock

SKU: 99140-131
Smart Door Lock
 Door Locks,Doorbell,Hardware,Home Safety,Kwikset Locks,Smart Home
Braeburn Digital Thermostat
Programmable wi fi thermostat
Affordable wifi thermostat

This Kwikset 2nd Gen Round Smart Lock is step up to designer styles and superior security with Kwikset Signature Series products. The Signature series deadbolt with Home Connect technology enables the lock to wirelessly communicate with other devices in the home. The lock allows the user through a web-enabled device to remotely check the door lock status, lock or unlock the door and receive notifications via email or text. This single cylinder deadbolt can be locked or unlocked by using the keypad or key from the outside as well as the turn button from the inside. The Venetian Bronze finish is hand-rubbed to reveal unique bronze highlights and provides a rich and warm complement to the product's style.

  • Motor-driven deadbolt latch allows for true remote locking and unlocking
  • Check the status of the door if its locked or unlocked
  • Z-Wave Plus certified with the Z-Wave 500 chipset
  • Extended wireless range and superior 128-bit wireless encryption
  • Tapered designed latch enables misaligned doors to lock without pushing or pulling a door shut
  • BHMA grade 2 certified
  • SmartKey Security technology - the lock you can re-key yourself in seconds in 3 easy steps
  • SmartKey Security re-key technology is compatible with Kwikset (KW1) keyway
  • Patented side locking bar technology offers improved security by protecting against lock bumping, an attack technique used to defeat conventional pin and tumbler locks
  • Installs in minutes with just a screwdriver no hard wiring needed
  • Fits standard doors (1-3/8 in.- 2 in.) no new screw holes required
  • Lifetime mechanical and finish warranty, 1-year electronics warranty
  • UL certified 20-minute fire rating
  • Certifications and Listings: ANSI Certified


Faceplate Depth (in.) 1.16 Required door thickness (in.) 1 3/8 to 2
Faceplate height (in.) 2.63 Strike plate height (in.) 2.75
Faceplate width (in.) 2.63 Strike plate width (in.) 1.125
Projection (in.) 1.16


Battery Size AA Battery Lock Type Single Cylinder Deadbolt
Commercial/Residential Residential Material Metal
Deadbolt Type Single Cylinder Deadbolt Number of Batteries Required 4
Door Handing Universal/Reversible Power Options Battery
Door Lock Style Classic Power Source Self Powered
Door Locks & Knobs Product Type Deadbolts Product Weight (lb.) 2.5lb
Features Adjustable Backset, Automatic Relocking, Easy Installation, Fail-Safe Operation, Smart Key Remote Access Remote Access
Finish Venetian Bronze Requires Hub? Hub Required for Remote Access
Hardware Included

Lock Only Security/ANSI Grade

ANSI Grade 2 (Better)
Holding force (lb.) 0 Smart Home

Smart Home Enabled
Hub Required: Nexia Gateway, Samsung SmartThings Hub, Staples Connect D-Link Hub, VeraEdge Hub, VeraSecure Hub, VersPlus Hub, Wink Hub Smart Home Protocol

Total Number of Keys Included 2 Voice Control Hub Required Alexa via Samsung SmartThings Hub, Wink Hub
Wired or Wireless
Works With Alexa, Nexia, Samsung SmartThings, WeMo


Before you start re-keying, you must have your functioning key, your new key, and the SmartKey Learn tool. Insert the key that currently operates your lock, and rotate it 90 degrees clockwise. A) Insert the SmartKey tool fully and firmly into the SmartKey hole.

B) Remove the SmartKey tool and the current key.
A) Fully insert your new key into the lock and rotate it 180 degrees.

B) Rotate the new key 90 degrees back to the starting position, and remove it. Your lock is now re-keyed to your new key, and your old key will no longer operate the lock.
