RAB Lighting FFLED39W Future Flood 39W Cool LED, 120V/277V, White

$ 290.00 $ 249.99
Availability: In Stock

Lighting Type LED
LED Type:
Two multi-chip, 26Watt high-performance LEDs
Color Temp 5000K (Cool)
Wattage 39
Lifespan 100,000 Hours

SKU: FFLED39W
Floodlight
RAB Lighting
 Floodlights,Outdoor Lighting,RAB Outdoor Lighting
Description

The RAB Lighting FFLED39W Future Flood 39W Cool LED, 120V/277V, White is an Ultra-efficient LED and optical design that is Replaces a 150W MH floodlights with over 100,000-hour life based on LM-80 tests.

Type Constant Current
120V 0.35A
208V 0.20A
240V 0.18A
277V 0.15A
Input Watts 41.8A
Watts 39W
Color Temp 5000K (Cool)
Lumens 5,666
Efficacy 135.6 Im/W
Color Accuracy 71 CRI
L70 Lifespan 100,000 Hours
Specs.

LED Characteristics.
Lifespan. 100,000-hour LED lifespan based on IES LM-80 results and TM-21 calculations
Note All values are typical (tolerance +/- 10%)
LEDs Two multi-chip, 26Watt high-performance LEDs
Color Consistency  7-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color
Color Stability LED color temperature is warrantied to shift no more than 200K in CCT over a 5-year period
Color Uniformity RAB's range of CCT (Correlated Color Temperature) follows the guidelines of the American National Standard for (SSL) Products, ANSI C78.377-2017.
  • Listings
    DLC Listed This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. DLC Product Code: P00001709
    IESNA LM-79 & LM-80 Testing RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
    UL Listing Suitable For Wet Locations. Suitable for ground mounting.
    Construction
    IP Rating Ingress Protection rating of IP66 for dust and water
    Ambient Temperature Suitable For use in 40°C (104°F)
    Cold Weather Starting Minimum starting temperature is -40°C (-40°F)
    Thermal Management Housing Superior heat sinking with external Air-Flow fins
    Mounting Heavy-duty mounting arm with "O" ring seal & stainless steel screw
    Effective Projected Area EPA = 0.65
    Reflector Specular vacuum-metalized polycarbonate
    Gaskets High-temperature silicone gaskets
    Finish Formulated for high durability and long-lasting color
    Green Technology Mercury and UV free. RoHS-compliant components.
    Threaded Size 1/2" threaded arm
    Optical
    NEMA Type NEMA Beam Spread of 7H x 6V
    Electrical
    Driver Constant Current, Class 2, 1050mA, 100-277V, 50/60Hz, 0.6A, Power Factor 99%
    Surge Protection 4kV
    Warranty RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
