Grandstream 4-port FXO Gateway, GXW4104

$ 171.49
Availability: In Stock
The GXW FXO IP Analog Gateway series offers the small enterprise, SOHO, remote offices and multi-location enterprises a cost-effective, easy to deploy VoIP FXO solution. The GXW410x series allows any...
SKU: GXW4104
VoIP Gateway
Grandstream
 Best Selling Products,Newest Products,Telecommunication
Description
The GXW FXO IP Analog Gateway series offers the small enterprise, SOHO, remote offices and multi-location enterprises a cost-effective, easy to deploy VoIP FXO solution. The GXW410x series allows any business to seamlessly connect multiple locations with up to 8 PSTN lines, to an IP PBX system, or with an existing traditional phone system.

The GXW410x FXO gateway series enables businesses of all sizes to create and deploy a VoIP and analog hybrid solution. Make deployments easy by seamlessly connect multiple locations and all devices within an office to any hosted or on-premise IP PBX network.

Features:
  • Product Name - Mid-Density Gateway 4 Fxo Ports NAT Router
  • Product Series - GXW410x
  • Product Model - GXW4104
  • Product Type - VoIP Gateway
  • 2 10/100 Mbps network ports
  • Comprehensive codec support, caller ID, flexible dial plans and security protection
  • Advanced security protection with SRTP
  • Designed and tested for full interoperability with leading IP-PBX, soft-switches and SIP-based environments
  • PSTN Failover on power failure
Interfaces/Ports.
  • PoE (RJ-45) Port No
  • USB No
  • Number of Network (RJ-45) Ports 2
  • Number of FXO (RJ-11) Ports 4
  • SIM Card Supported - No

Networking.


  • Form FactorExternal
  • Connectivity TechnologyWired
  • Data Link ProtocolEthernet, Fast Ethernet
  • Network / Transport ProtocolPPPoE
  • Remote Management Protocol HTTP
  • Status IndicatorsPort status, power
  • FeaturesSwitching, routing, NAT support, VLAN support, DiffServ support, manageable, wall mountable
  • Compliant StandardsIEEE 802.1Q, IEEE 802.1p

IP Telephony.


  • VoIP ProtocolsSIP
  • Voice Code csG.723, G.729, G.711u, G.711a, T.38
  • Telephony Interfaces4 line (FXO)
  • IP Telephony FeaturesEcho cancellation (G.168), caller ID, adaptative jitter buffer

Expansion / Connectivity.


  • Interfaces4 x modem - RJ-11 ¦ 1 x 100Base-TX - RJ-45 ¦ 1 x 100Base-TX - RJ-45 (WAN) ¦ 1 x video

Miscellaneous.


  • Compliant StandardsUL, EN55022, EN55024, FCC Part 15 B, FCC Part 68

Power.


  • Power DeviceExternal power adapter
  • Voltage Required AC 120/230 V (50/60 Hz)
    Physical Characteristics.

    • Height 1.4"
    • Width 5.3"
    • Depth 8.9"

    Form Factor.


    • Rack-mountable
    • Desktop
    • Wall Mountable

    Environmental Parameters.


    • Min Operating Temperature41 °F
    • Max Operating Temperature113 °F
    • Humidity Range Operating10 - 90%
